Handed Pocket Lockset
Barrier-Free (ADA Compliant)
The C-50FP Privacy Lockset is a comprehensive barrier-free solution designed to meet ADA compliance standards for pocket doors. This lockset ensures the door fully retracts into the pocket, with handles extending on both sides for universal accessibility. Simply tilting the interior handle locks the door securely. The set comes complete with modern black nylon handles and is equiped with an emergency release feature, offering an additional layer of safety by enabling external unlocking, providing you with peace of mind. Crafted specifically for wooden doors, it's offered in flat black or satin stainless steel, with option for custom finishing available.
Frame Thickness: 4.75 in [120.6 mm] to 10 in [254 mm]
Door Thickness: 1 3/8 in [34.9 mm] to 1 3/4 in [44.5 mm]
Strike Plate: 1 in [25.4 mm] x 2 3/4 in [69.9 mm]
Dustproof Box: included
Handing: specify left or right
Included Components: one C-50FP Full Privacy Pocket Lockset
C-50FP-A x ( ) LH
For 4.75 in [120.7 mm] to 5.5 in [139.7 mm] frame thickness
Left-Handed
C-50FP-A x ( ) RH
For 4.75 in [120.7 mm] to 5.5 in [139.7 mm] frame thickness
Right-Handed
C-50FP-B x ( ) LH
For 5.75 in [146.1 mm] to 7 in [177.8 mm] frame thickness
Left-Handed
C-50FP-B x ( ) RH
For 5.75 in [146.1 mm] to 7 in [177.8 mm] frame thickness
Right-Handed
C-50FP-C x ( ) LH
For 7.25 in [184.2 mm] to 8.5 in [215.9 mm] frame thickness
Left-Handed
C-50FP-C x ( ) RH
For 7.25 in [184.2 mm] to 8.5 in [215.9 mm] frame thickness
Right-Handed
C-50FP-D x ( ) LH
For 8.75 in [222.3 mm] to 10 in [254 mm] frame thickness
Left-Handed
C-50FP-D x ( ) RH
For 8.75 in [222.3 mm] to 10 in [254 mm] frame thickness
Right-Handed
( ) = finish
